Chevy Bolt and Equinox EV Home Charging: What You Need to Know

Chevy's EV lineup offers some of the best value in the market, but the Bolt EV/EUV and the Equinox EV run different onboard chargers, and that single spec decides which home charger is worth buying. Get the amperage match wrong and you either pay for speed the car cannot use or bottleneck a car that could charge faster.

Onboard Charger Specs by Model

Bolt's Onboard Charger Caps the Speed You Can Buy

The Bolt's onboard charger maxes out at 32A (7.7 kW) no matter what you plug it into. Buying a 48A or 64A home charger for a Bolt buys nothing extra today, since the car's onboard converter, not the wall unit, sets the ceiling. A 40A charger like the Grizzl-E ($399) delivers the exact same charging speed as a $700 ChargePoint Home Flex set to 50A, because both are capped by the same 32A onboard limit.

The Equinox EV is a different story. The base 1LT/2LT trims run a 48A/11.5 kW onboard charger, and the 3RS trim jumps to 64A/19.2 kW, the fastest AC onboard rate GM currently ships. Matching a 48A or 60A home charger to the Equinox actually shortens real charging time, unlike on the Bolt.

Best Charger Picks by Model

For Chevy Bolt EV/EUV (32A onboard, 7.7 kW cap)

• Best value: Grizzl-E Classic ($399), 40A output exceeds what the Bolt can draw, rock-solid reliability, 24 ft cable
• Best smart: Grizzl-E Smart ($499), adds WiFi scheduling for time-of-use rates without changing charge speed
• Best if upgrading cars later: ChargePoint Home Flex ($649), adjustable 16-50A, ready for a future 48A or 60A car

For Equinox EV 1LT/2LT (48A onboard, 11.5 kW cap)

• Best overall: ChargePoint Home Flex ($649) set to 48A, matches the onboard charger exactly
• Best design: Wallbox Pulsar Plus ($549), compact housing, 48A output, built-in load management
• Best budget: Grizzl-E Classic ($399), capped at 40A output, roughly 17% slower than the car's true 48A ceiling but a meaningful savings

For Equinox EV 3RS (64A onboard, 19.2 kW cap)

• Best match: Wallbox Pulsar Plus 60A or ChargePoint Home Flex at 50A, both undercut the car's 64A ceiling slightly but require only a 60A or 70A breaker instead of an 80A circuit
• Note: Very few residential Level 2 chargers exceed 50A; feeding the 3RS's full 64A rate typically means a hardwired 80A circuit and an 80A-rated charger, which raises both equipment and installation cost

Breaker Sizing and the NEC 80% Rule

Under NEC Article 625 and the continuous-load provision in NEC 210.19, an EV charging circuit is treated as a continuous load, meaning the breaker must be sized at 125% of the charger's maximum continuous draw, or equivalently the charger should be run at no more than 80% of the breaker's rating. A 48A charger needs a 60A breaker (48 / 0.8 = 60). A 40A charger needs a 50A breaker. A 32A charger needs a 40A breaker. This is why a Bolt owner running a 40A Grizzl-E needs a 50A circuit even though the car itself only pulls 32A, the charger's rated output, not the car's draw, is what sizes the breaker.

Charge Time Math: Empty to Full

The formula is simple: battery capacity in kWh divided by charger output in kW equals hours to full, adjusted for roughly 10-15% charging losses. For a Bolt EV/EUV with a 65 kWh pack on a 7.7 kW onboard limit, that is 65 / 7.7 = 8.4 hours before losses, matching the 8-9 hour window GM publishes. For an Equinox EV 2LT with an 85 kWh pack on an 11.5 kW limit, 85 / 11.5 = 7.4 hours, again lining up with GM's stated 7-8 hours. For the 3RS at 19.2 kW, 85 / 19.2 = 4.4 hours, close to the roughly 5-hour figure GM quotes once losses are factored in.

Bolt Battery Recall: What Owners Should Know

The 2020-2022 Bolt EV/EUV was subject to a 2021 GM/LG Chem battery recall tied to a manufacturing defect that could cause fire risk in a small number of packs. GM replaced affected battery modules under warranty at no cost to owners, and the recall has been resolved industry-wide since 2022; current Bolt production and used units that received the replacement carry no elevated risk tied to that issue. If you are buying a used Bolt, confirm with a dealer or via the VIN recall lookup that the battery replacement was completed.

Using the myChevrolet App for Scheduling

All Chevy EVs support charge scheduling through the myChevrolet app, including departure times, charging windows, and location-based charging preferences. If you buy a basic non-smart charger, the car's app handles scheduling for free, which removes the need to pay extra for a WiFi-connected unit purely for scheduling.

Total Setup Cost Estimate

A Grizzl-E Classic ($399) paired with myChevrolet app scheduling gives reliable overnight charging with time-of-use rate optimization for under $400 in equipment. Add a typical installation in the $300-$700 range, depending on how far the panel sits from the parking spot and whether a subpanel or new circuit run is needed, and the full setup lands under $1,100 before any federal or state tax credits. Use our Charger Install Cost Estimator to get a number specific to your panel distance and amperage.

NEMA Plug Types for Portable and Hardwired Setups

Most Level 2 chargers for Bolt or Equinox owners install one of two ways: hardwired directly into the panel, or plugged into a NEMA 14-50 outlet, the same 50A/240V receptacle used for RV hookups and electric ranges. A NEMA 14-50 install gives flexibility to unplug and relocate the charger, while hardwiring is required by some manufacturers to qualify for the longer warranty and is generally the more weatherproof option for an outdoor mount. Avoid adapting a NEMA 6-50 or TT-30 outlet without confirming the charger's compatibility list; a TT-30 (30A, no neutral, common on older RV pads) is not rated for a 40A or 48A charger and will trip the circuit under sustained load.

Troubleshooting Common Charging Issues

If the Bolt or Equinox reports a slower-than-expected charge rate, check three things in order. First, confirm the charger's amperage dial or app setting matches the circuit's breaker rating, not just the car's onboard maximum, since a charger left at a lower manual setting from a previous vehicle will silently under-deliver. Second, check for thermal derating, some chargers reduce output automatically above roughly 104°F ambient temperature, which matters for a garage-mounted unit in summer. Third, verify the myChevrolet app is not applying a stored charge limit, such as an 80% cap left over from a road trip setting, which will end the session early even though the charger itself is working correctly.
